MICROWAVE LINKS >>HIGH POWER MICROWAVE LINKS
WIDEBAND MICROWAVE LINK MODEL XLD-1015/H FOR 1.0 GHz-1.5 GHz WITH DIGITAL DISPLAY

Model: XLD-1015/HP
Price: call

Recommended for Government agencies. This microwave link is a wideband link for operations from 1000-1500 MHz with no gaps or limits. The frequency is adjustable in 125 kHz step all the way from 1000 MHz -1500 MHz. The transmitter has 5W power. Two special antennas 9.0 dB gain LOG1216 are included. Capacity: 1 video/2 audio channels. Operating frequency: synthesized. This link is Professional and it is recommended for special applications or video surveillance . It is made for long distances - up to 20 miles line-of-sight. Frequency setting is external and easy to tune by two push buttons.
Dimensions:
Receiver: 7.5 " X 11 " X 3.5 ".
Transmitter: 7.5 " X 11 " X 3.5 ".

MORE INFO
CONTACT

Regulated power supplies, antennas and RF cables are included.

8 CHANNELS 1.9-2.1 GHz MICROWAVE LINK MODEL XLD-1900/HP WITH DIGITAL DISPLAY

Model: XLD-1900/HP
Price: Call

Special order, Recommended for Government agencies only. 10W transmitter with receiver, 2 special antennas 9.5 dB gain LOG3/GR, Capacity: 1 video/2 audio channels. Operating frequency: synthesized. This link is Professional synthesized with a digital display inside, and it is recommended for special applications or video surveillance . It is made for long distances - up to 35 miles line-of-sight. Frequency setting is internal.
Dimensions:
Receiver: 7.5 " X 11 " X 3.5 ".
Transmitter: 7.5 " X 11 " X 3.5 ".

MORE INFO
CONTACT

Regulated power supplies, antennas and RF cables are included.

Distances up 35 km with the special antenna PH-24L



8 CHANNELS MICROWAVE LINK MODEL XLS-2000/HP FOR 2.4 GHz

Model: XLS-2000/HP
Price: Call

10 W transmitter with 8 channels, 8 channel receiver, 2 directional antennas LOG1/GR , Capacity: 1 video/2 audio channels, receiver has built-in low noise amplifier for excellent sensitivity. Operating frequency: synthesized. This link is Professional and it is recommended for TV production and Film. It is made for very long distances - up to 35 km line-of-sight. Frequency setting is internal. Both receiver and transmitter are built in weatherproof NEMA enclosures.
Dimensions:
Receiver: 7.5 " X 11 " X 3.5 ".
Transmitter: 7.5 " X 11 " X 3.5 ".

MORE INFO
MANUAL
CONTACT

Regulated power supplies, antennas and RF cables are included.

Distances up 35 km with the special antenna PH-24L



10 W MICROWAVE LINK MODEL XLD-2000HP WITH DIGITAL DISPLAY FOR 2.4 GHz

Model: XLD-2000/HP
Price: Call

10 W transmitter , receiver, 2 directional antennas LOG1/GR, Capacity: 1 video/2 audio channels, receiver has built-in low noise amplifier for excellent sensitivity. Operating frequency: synthesized with a digital display inside the unit. This link is Professional and it is recommended for TV production and Film. It is made for very long distances - up to 35 km line-of-sight. Frequency setting is internal. Both receiver and transmitter are built in aluminumweatherproof NEMA enclosures.
Dimensions:
Receiver: 7.5 " X 11 " X 3.5 ".
Transmitter: 7.5 " X 11 " X 3.5 ".

MORE INFO
MANUAL
CONTACT

Regulated power supplies, antennas and RF cables are included.

Distances up 35 km with the special antenna PH-24L



MICROWAVE LINK MODEL XLD-4961 wITH DIGITAL DISPLAY 1.5 W

Model: XLD-4961
Price: Call

setup

XLD-4961 is an excellent, easy to use microwave link for wide range of frequencies. It has continues frequency coverage from 4,950 MHz- 6,100 MHz that makes this equipment unique in the world. RF output power is 1.5 W. An LCD display shows any frequency from 4,950 MHz- 6,100 MHz with step 500 kHz. The system contains: a special receiver with digital display, 2 directional antennas PK-4960; Capacity: 1 video/2 audio channels; the receiver has built-in low noise amplifier for increased sensitivity. Operating frequency: synthesized. This link is Professional and it is recommended for TV production and Film. It is made for very long distances - up to 20 km + line-of-sight with high gain antennas. Frequency setting is external and simple by push-buttons. Both receiver and transmitter are built in special weatherproof NEMA enclosures. The transmitter is self-adjustable and protected in case that antenna is not properly matched.
Dimensions:
Receiver: 7.5 " X 11 " X 3.5 ".
Transmitter: 7.5 " X 11 " X 3.5 ".

MORE INFO
CONTACT

*distances up 30 km with the special antennas PK-4961.

MICROWAVE LINK MODEL XLD-4961/H wITH DIGITAL DISPLAY 5 W

Model: XLD-4961/H
Price:Call

setup

XLD-4961/H is an excellent, easy to use microwave link for wide range of frequencies. It has continues frequency coverage from 4,950 MHz- 6,100 MHz that makes this equipment unique in the world. RF output power is 5 W. An LCD display shows any frequency from 4,950 MHz- 6,100 MHz with step 500 kHz. The system contains: a special receiver with digital display, 2 directional antennas PK-4960; Capacity: 1 video/2 audio channels; the receiver has built-in low noise amplifier for increased sensitivity. Operating frequency: synthesized. This link is Professional and it is recommended for TV production and Film. It is made for very long distances - up to 30 km + line-of-sight with high gain antennas. Frequency setting is external and simple by push-buttons. Both receiver and transmitter are built in special weatherproof NEMA enclosures. The transmitter is self-adjustable and protected in case that antenna is not properly matched.
Dimensions:
Receiver: 7.5 " X 11 " X 3.5 ".
Transmitter: 7.5 " X 11 " X 3.5 ".

MORE INFO
CONTACT

*distances up 30 km with the special antennas PK-4961.

10 W LOW COST MICROWAVE LINK MODEL XLS-5800/HP FOR 5.8 GHz

Model: XLS-5800/HP
Price: call

setup

XLS-5800/HP is an excellent microwave link for 5.8 GHz. It includes: 10 W transmitter with 8 channels 5.750 MHz - 5.900 MHz, special 8 channels receiver, 2 directional antennas PT-58; Capacity: 1 video and 2 audio channels, receiver has built-in low noise amplifier for increased sensitivity. Operating frequency: synthesized. This link is Professional and it is recommended for TV production and Film. It is made for very long distances - up to 40 km line-of-sight. Frequency setting is internal. Both receiver and transmitter are built in weatherproof NEMA enclosures.
Dimensions:
Receiver: 7.5 " X 11 " X 3.5 ".
Transmitter: 7.5 " X 11 " X 3.5 ".

MORE INFO
MANUAL
CONTACT

*distances up 70 km with the special antennas PR-58.

10 WLOW COST MICROWAVE LINK MODEL XLD-5800/HP WITH DIGITAL DISPLAY FOR 5.8 GHz

Model: XLD-5800/HP
Price: Call

setup

XLD-5800/HP is an excellent microwave link for 5.8 GHz. It comes with 10 W transmitter with digital display to acces any frequency from 5.600 MHz - 5.900 MHz, special receiver with digital display, 2 directional antennas PT-58 ; Capacity: 1 video/2 audio channels, receiver has built-in low noise amplifier for increased sensitivity. Operating frequency: synthesized. This link is Professional and it is recommended for TV production and Film. It is made for very long distances - up to 40 km line-of-sight. Frequency setting is internal. Both receiver and transmitter are built in weatherproof NEMA enclosures.
Dimensions:
Receiver: 7.5 " X 11 " X 3.5 ".
Transmitter: 7.5 " X 11 " X 3.5 ".

MORE INFO
MANUAL
CONTACT

*distances up 70 km with the special antennas PR-58.
