BROADCAST QUALITY MICROWAVE LINKS >>5800 MHz MICROWAVE LINKS
MICROWAVE LINK MODEL XLD-4961 wITH DIGITAL DISPLAY 1.5 W

Model: XLD-4961
Price: Call

setup

XLD-4961 is an excellent, easy to use microwave link for wide range of frequencies. It has continues frequency coverage from 4,950 MHz- 6,100 MHz that makes this equipment unique in the world. RF output power is 1.5 W. An LCD display shows any frequency from 4,950 MHz- 6,100 MHz with step 500 kHz. The system contains: a special receiver with digital display, 2 directional antennas PK-4960; Capacity: 1 video/2 audio channels; the receiver has built-in low noise amplifier for increased sensitivity. Operating frequency: synthesized. This link is Professional and it is recommended for TV production and Film. It is made for very long distances - up to 20 km + line-of-sight with high gain antennas. Frequency setting is external and simple by push-buttons. Both receiver and transmitter are built in special weatherproof NEMA enclosures. The transmitter is self-adjustable and protected in case that antenna is not properly matched.
Dimensions:
Receiver: 7.5 " X 11 " X 3.5 ".
Transmitter: 7.5 " X 11 " X 3.5 ".

MORE INFO
CONTACT

*distances up 30 km with the special antennas PK-4961.

MICROWAVE LINK MODEL XLD-4961/H wITH DIGITAL DISPLAY 5 W

Model: XLD-4961/H
Price: Call

setup

XLD-4961/H is an excellent, easy to use microwave link for wide range of frequencies. It has continues frequency coverage from 4,950 MHz- 6,100 MHz that makes this equipment unique in the world. RF output power is 5 W. An LCD display shows any frequency from 4,950 MHz- 6,100 MHz with step 500 kHz. The system contains: a special receiver with digital display, 2 directional antennas PK-4960; Capacity: 1 video/2 audio channels; the receiver has built-in low noise amplifier for increased sensitivity. Operating frequency: synthesized. This link is Professional and it is recommended for TV production and Film. It is made for very long distances - up to 30 km + line-of-sight with high gain antennas. Frequency setting is external and simple by push-buttons. Both receiver and transmitter are built in special weatherproof NEMA enclosures. The transmitter is self-adjustable and protected in case that antenna is not properly matched.
Dimensions:
Receiver: 7.5 " X 11 " X 3.5 ".
Transmitter: 7.5 " X 11 " X 3.5 ".

MORE INFO
CONTACT

*distances up 30 km with the special antennas PK-4961.

MICROWAVE LINK 5 W MODEL XLS-5800/H

Model: XLS-5800/H
Price: call

setup

XLS-5800/H is an excellent microwave link for 5.8 GHz. It includes: 5 W transmitter with 8 selectable channels, special 8 channels receiver, 2 directional antennas PT-58 ; Capacity: 1 video and 2 audio channels; receiver has built-in low noise amplifier for increased sensitivity. Operating frequency: synthesized. This link is Professional and it is recommended for TV production and Film. It is made for very long distances - up to 20 km line-of-sight. Frequency setting is internal. Both receiver and transmitter are built in weatherproof NEMA enclosures.
Dimensions:
Receiver: 7.5 " X 11 " X 3.5 ".
Transmitter: 7.5 " X 11 " X 3.5 ".

MORE INFO
MANUAL
CONTACT

*distances up 40 km with the special antennas PR-58.

MICROWAVE LINK 10 W MODEL XLS-5800/HP

Model: XLS-5800/HP
Price: Call

setup

XLS-5800/HP is an excellent microwave link for 5.8 GHz. It includes: 10 W transmitter with 8 channels 5.750 MHz - 5.900 MHz, special 8 channels receiver, 2 directional antennas PT-58; Capacity: 1 video and 2 audio channels, receiver has built-in low noise amplifier for increased sensitivity. Operating frequency: synthesized. This link is Professional and it is recommended for TV production and Film. It is made for very long distances - up to 40 km line-of-sight. Frequency setting is internal. Both receiver and transmitter are built in weatherproof NEMA enclosures.
Dimensions:
Receiver: 7.5 " X 11 " X 3.5 ".
Transmitter: 7.5 " X 11 " X 3.5 ".

MORE INFO
MANUAL
CONTACT

*distances up 60 km with the special antennas PR-58.

MICROWAVE LINK 15 W MODEL XLS-5800/HPR

Model: XLS-5800/HPR
Price: Call

setup

XLS-5800/HP is an excellent microwave link for 5.8 GHz. It includes: 15 W transmitter with 8 channels 5.750 MHz - 5.900 MHz, special 8 channels receiver, 2 directional antennas PT-58; Capacity: 1 video and 2 audio channels, receiver has built-in low noise amplifier for increased sensitivity. Operating frequency: synthesized. This link is Professional and it is recommended for TV production and Film. It is made for very long distances - up to 50 km line-of-sight. Frequency setting is internal. Both receiver and transmitter are built in weatherproof NEMA enclosures.
Dimensions:
Receiver: 7.5 " X 11 " X 3.5 ".
Transmitter: 7.5 " X 11 " X 3.5 ".

MORE INFO
MANUAL
CONTACT

*distances up 70 km with the special antennas PR-58.

MICROWAVE LINK MODEL XLD-5800/H wITH DIGITAL DISPLAY

Model: XLD-5800/H
Price: Call

setup

XLD-5800/H is an excellent, easy to use microwave link for 5.8 GHz. It comes with 5 W transmitter (XLD-5800/H) or 10 W Transmitter (XLD-5800/HP) with digital display to access any frequency from 5.690 MHz - 5.900 MHz, special receiver with digital display, 2 directional antennas PH-58 ; Capacity: 1 video/2 audio channels, receiver has built-in low noise amplifier for increased sensitivity. Operating frequency: synthesized. This link is Professional and it is recommended for TV production and Film. It is made for very long distances - up to 30 km + line-of-sight with higher gain antennas. Frequency setting is external and simple by push-buttons. Both receiver and transmitter are built in special weatherproof NEMA enclosures. The transmitter is self-adjustable in case that antenna is not properly matched.
Dimensions:
Receiver: 7.5 " X 11 " X 3.5 ".
Transmitter: 7.5 " X 11 " X 3.5 ".

MORE INFO
CONTACT

*distances up 70 km with the special antennas PR-58.

MICROWAVE LINK MODEL XLD-5800/HP WITH DIGITAL DISPLAY

Model: XLD-5800/HP
Price: Call

setup

XLD-5800/H is an excellent, easy to use microwave link for 5.8 GHz. It comes with 5 W transmitter (XLD-5800/H) or 10 W Transmitter (XLD-5800/HP) with digital display to access any frequency from 5.690 MHz - 5.900 MHz, special receiver with digital display, 2 directional antennas PH-58 ; Capacity: 1 video/2 audio channels, receiver has built-in low noise amplifier for increased sensitivity. Operating frequency: synthesized. This link is Professional and it is recommended for TV production and Film. It is made for very long distances - up to 30 km + line-of-sight with higher gain antennas. Frequency setting is external and simple by push-buttons. Both receiver and transmitter are built in special weatherproof NEMA enclosures. The transmitter is self-adjustable in case that antenna is not properly matched.
Dimensions:
Receiver: 7.5 " X 11 " X 3.5 ".
Transmitter: 7.5 " X 11 " X 3.5 ".

MORE INFO
CONTACT

*distances up 70 km with the special antennas PR-58.

LOW COST MICROWAVE LINK MODEL XLS-5800

Model: XLS-5800
Price: $1,499.00 USD

setup in stock

XLS-5800 is excellent low cost microwave link for 5.8 GHz. It comes with 600 mW transmitter with 8 channels, 8 channels receiver, 2 directional antennas PT-58 ; Capacity: 1 video/2 audio channels, receiver has built-in low noise amplifier for increased sensitivity. Operating frequency: synthesized. This link is Professional and it is recommended for TV production and Film. It is made for very long distances - up to 7 km line-of-sight. Frequency setting is internal. Both receiver and transmitter are built in weatherproof NEMA enclosures.
Dimensions:
Receiver: 8 " X 6 " X 4 ".
Transmitter: 8 " X 6 " X 4 ".

MORE INFO
MANUAL
CONTACT

*distances up 15 km with the special antennas PR-58.

LOW COST 8 CHANNELS MICROWAVE LINK MODEL XLS-5800 WITH 2 VIDEO AND 4 AUDIO CHANNELS

Model: XLSW-5800
Price: Call

setup in stock

XLSW-5800 is excellent low cost microwave link for 5.8 GHz. It comes with 600 mW transmitters with 8 channels, (two transmitters are built-in); 8 channels receivers, 4 Omni directional antennas AX-58R ; Capacity: 2 Video / 4 audio channels, the receiver has built-in low noise amplifier for increased sensitivity and band-pass filters. Operating frequency: synthesized. This link is Professional and it is recommended for TV production and Film. It is made for very long distances - up to 7 km line-of-sight. Frequency setting is internal. Both receiver and transmitter are built in weatherproof NEMA enclosures.
Dimensions:
Receiver: 8 " X 6 " X 4 ".
Transmitter: 8 " X 6 " X 4 ".

MORE INFO
CONTACT

*distances up 15 km with the special antennas PR-58.
